Physical Specifications
- Built dimensions: 56 x 43 x 71 in/142 x 109 x 180 cm
- Weight: 600 lb/272 kg
Technical Specifications
- Heavy duty 2" x 4" 11-gauge oval steel frames combined with 2" 11-gauge round tubing accents
- All welded construction by inert-gas MIG welding confirming with all Structural Welding Code - Steel Standards and Specifications
- Sealed 2" roller bearings and 1" diameter solid steel axle encased in machined housing on all primary pivot points
- 1" solid steel axles with 1" bronze oil lite bushings on all secondary pivot points
- 4-1/2" and 3-1/2" diameter fiberglass reinforced nylon pulleys with sealed bearings enclosed in protective steel covers
- High density EMR Urethane foam padding with double-stitched upholstery secured to 3/4" plywood backing
- Electrostatic powder coat finish in Platinum Sparkle with Charcoal accents (other color options available for additional charge)
- USA-Made/Certified 2200 lbs. 3/16" military-spec nylon coated cable
- Magnetically secured selector pins and steel weight stacks are easily accessible from seated position
- 3/4" precision ground, hard chrome finish, solid steel guide rods
- Composite SMC safety weight stack enclosures with decorative built-in storage compartment cover
- Biomechanically designed 7-gauge steel cams provide proper resistance curves throughout full range of motion
- Thermoplastic rubber handgrips secured with aluminum end caps for durability and improved feel
- Protective rubber stabilizer feet with anchoring holes provided on all machines
- 220 lb. weight stack (optional 295 lb. weight stack available)
